GUIDE

PandJS - building own JavaScript runtime

In this article we will discuss how to build own JavaScript runtime and challanges I experience in my side project.

avatar
Michał Dziuba · 11 min read

Introduction

Writing own JavaScript runtime “from scratch” is fairly demanding project - I have to design event loop, write lower level API for interaction with operating system and then integrate everything into runtime with v8 engine.

I decided to write event loop in C as seperated project pandio - it is supposed to abstract any operating system differences and provide API for networking, timers, file system, signals and more. It’s heavily inspired by libuv, but I wanted to write my own thing, because I think this is actually core of how runtime behaves - so I don’t want to use ready solutions. In addition - I just wanted to learn in details how typical event loop works, so how you can learn such thing? Build your own event loop.

For runtime itself, I decided to go with C++, mainly because v8 is written in C++ and it relies on typical features like RAII and smart pointers, so writing own FFI wrapper for v8 is not easy task (Deno did it with their rusty-v8).

At the beginning I also want to say that I am not advanced C/C++ programmer, I use them “more seriously” less than one year. I still discover how things work.

Intro into non-blocking architecture

This is typical blocking TCP server written in C. This is peak of what you can find in most C tutorials from YouTube. This server must handle fully first connection before it will accept next one.

#define PORT 8080
#define BUFFER_SIZE 1024

int main() {
    int server_fd, client_fd;
    struct sockaddr_in address;
    int addrlen = sizeof(address);
    char buffer[BUFFER_SIZE] = {0};

    if ((server_fd = socket(AF_INET, SOCK_STREAM, 0)) == 0) {
        perror("socket failed");
        exit(EXIT_FAILURE);
    }

    address.sin_family = AF_INET;
    address.sin_addr.s_addr = INADDR_ANY;
    address.sin_port = htons(PORT);

    if (bind(server_fd, (struct sockaddr *)&address, sizeof(address)) < 0) {
        perror("bind failed");
        close(server_fd);
        exit(EXIT_FAILURE);
    }

    if (listen(server_fd, 3) < 0) {
        perror("listen failed");
        close(server_fd);
        exit(EXIT_FAILURE);
    }
    printf("listen port: %d...\n", PORT);

    while (1) {
        if ((client_fd = accept(server_fd, (struct sockaddr *)&address, (socklen_t*)&addrlen)) < 0) {
            perror("accept failed");
            close(server_fd);
            exit(EXIT_FAILURE);
        }
        printf("New connection.\n");

        int valread = read(client_fd, buffer, BUFFER_SIZE);
        if (valread < 0) {
            perror("read failed");
        } else {
            buffer[valread] = '\0';
            printf("Received: %s\n", buffer);

            char *response = "Hello world";
            send(client_fd, response, strlen(response), 0);
        }

        close(client_fd);
        printf("Connection closed.\n");
    }

    close(server_fd);
    return 0;
}

For sure, this is not scalable, and there is multiple ways to make it non-blocking.

Traditional way of handling this issue is thread per connection model. We can create brand new thread for each connection. Drawbacks? Well, each thread has own seperated stack, so it is like allocating multiple MBs for each connection. Another issue? Context switching - average CPU doesn’t have 1000s cores to handle 1000s connections in pararell. In addition, if you have some shared state between connections, you will need proper synchronization with locks.

Reactor pattern - this is model we can find in software with high concurrency like Node.js and NGINX. The pattern’s key component is an event loop, running in a single thread. Every major operating system has own I/O event notification mechanism which acts as demultiplexer component. Linux has epoll, macOS/BSD kqueue and Windows has IOCP.

Handle is an abstract term for system resources like sockets, files, timers etc. It’s good to have some active handles counter - if you have active timer, your program should not finish early, right? If you start http server in Node.js app, it will wait, because it has at least one active handle (listening socket in this case).

This code below is literally event loop code from my pandio library. epoll_wait is blocking system call - it will wait until will receive some event like new connection to be accepted or timeout will expire (it will return 0 events on timeout).

void pd_io_run(pd_io_t *ctx) {
    struct epoll_event events[MAX_EVENTS];
    struct epoll_event ev;
    int timeout = pd_timers_next(ctx);
    pd_event_t *pev;

    // ctx->refs - counter of active handles
    while (ctx->refs > 0) {
        int events_count =
                epoll_wait(ctx->poll_fd, events, MAX_EVENTS, timeout);

        if (events_count == -1 && errno == EINTR) {
            // interrupted by signal
            continue;
        }

        if (events_count == -1) {
            perror("epoll_wait");
            exit(EXIT_FAILURE);
        }

        ctx->now = pd_now();

        for (int i = 0; i < events_count; ++i) {
            ev = events[i];
            unsigned pevents = 0;
            pev = ev.data.ptr;

            if (ev.events & EPOLLIN)
                pevents |= PD_POLLIN;

            if (ev.events & EPOLLOUT)
                pevents |= PD_POLLOUT;

            if (ev.events & (EPOLLERR | EPOLLHUP | EPOLLRDHUP)) {
                // usually we have to close handle in this scenario, so let's simplify detection
                pevents |= PD_CLOSE;

                if (ev.events & EPOLLERR)
                    pevents |= PD_POLLERR;

                if (ev.events & EPOLLHUP)
                    pevents |= PD_POLLHUP;

                if (ev.events & EPOLLRDHUP)
                    pevents |= PD_POLLRDHUP;

            }

            pev->handler(pev, pevents);
        }

        pd_timers_run(ctx);
        timeout = pd_timers_next(ctx);
        pd__tcp_pending_close(ctx);

        if (ctx->after_tick)
            ctx->after_tick(ctx);
    }
}

Timers

Timers actually are often implemented outside any operating system mechanism. Popular data structure is binary heap (min heap to be specific).

Each timer is a node and expiration time is a key inside the heap. We can check (just only read) next timer expiration in Θ(1), because it should be a root of the heap tree. If you want to delete/insert timer it will be Θ(log n) operation.

Another popular data structures for timers are: red-black-tree and timing wheel.

Getting current time is not cheap operation to be made on every timer insertion, becasue this is a system call. Currently I simply update current time at the beginning of every [event] loop cycle (iteration).

Mechanisms like epoll/kqueue/IOCP have timeout parameter, so we can easily calculate how long we want to wait for events and then pass it to the calls like epoll_wait:

int pd_timers_next(pd_io_t *ctx) {
    pd_timer_t *min = pd_timer_unwrap(heap_peek(&ctx->timers));
    if (min == NULL)
        return -1;

    uint64_t next_timeout = min->timeout - ctx->now;
    return (next_timeout >= INT_MAX) ? INT_MAX : (int)next_timeout;
}

When epoll_wait times out (or eventually receive events), we can re-evaluate our timers and execute any necessary callbacks.

Timers in PandJS/Node.js/Bun/Deno are not high-precision timers. You can easily delay them with long-running blocking functions. This is nature of single-threaded architecture of JS runtimes and it’s fine.

setTimeout(() => {
  console.log("3 seconds?");
}, 3000);

// some long-running blocking operation:
while (true) {}

in this sample setTimeout callback will be never called, because event loop is blocked

Thread pool

Demultiplexers like epoll cannot handle everything - they are useful mainly for pipes and sockets. Libraries like libuv use thread pool for operations on file system + Node.js uses this threadpool for some async operations inside crypto module, DNS lookups etc.

Thread pool is simply bunch of seperated threads created usually at the start of the program + synchronized tasks queue. You enqueue task to be performed in seperated thread, so it will not block your main thread. Tricky part is how to integrate thread pool with our event loop?

epoll/kqueue/iocp will wait until it will receive any event (like socket connection) or timeout, so likely our main thread will be blocked. So? At the end of the task, we need to send some signal to wake epoll/kqueue/iocp.

On unixes (epoll/kqueue) we can use “self-pipe” trick. If threadpool finishes it’s job, we can write one byte to pipe, at the same time epoll/kqueue watches read side of the pipe, so our loop will wake (receive event from pipe) and then it will check queue of finished tasks from threadpool.

There is also better mechanism on Linux - eventfd. It is more lightweight and made for this purpose in mind. The kernel overhead of an eventfd file descriptor is much lower than that of a pipe, and only one file descriptor is required (versus the two required for a pipe).

Actual integration with v8

v8 engine is non-trivial to build unfortunately and it’s also large project (compiles 40 minutes on my machine). This is not React where you have tutorials about every topic. If you want to learn something, you have to read large codebases of Node.js or/and Chromium.

If you are initially overwhelmed with large codebase, you can try to read some early versions - this is what I did with Node.js. It was much easier to learn about things with smaller codebase. Later I started to understand current codebase too.

v8 engine itself doesn’t have any event loop. Main purpose of v8 engine is to execute JavaScript code. Our responsibility is to write wrappers around handles from our event loop (tcp connections, timers).

C++ pointers and v8 garbage collector

When working with C++ and V8, it’s essential to consider V8’s garbage collector. This is particularly important when queuing up actions to be executed later that rely on references to JavaScript objects, such as timers or asynchronous TCP writes.

In the example code below, I create a wrapper for write operations in a TCP stream. Here, Buffer::getBytes() and Buffer::getSize() are my utility functions for extracting raw data from a Uint8Array in JavaScript, allowing us to work with byte offsets and lengths. Each write operation is queued for future execution (using epoll to notify when the stream is ready to write). However, in the meantime, the data from the Uint8Array could be garbage collected by V8 if not properly handled. To prevent this, we use v8::Persistent handles, which keep a reference to the wrapped value and prevent it from being prematurely garbage collected.

In the Writer struct’s destructor, we reset the v8::Persistent handle to allow the garbage collector to reclaim the associated memory once the write operation completes and the data is no longer needed.

Here is sample code:

template <typename TStream> struct Writer {
  TStream *stream;
  void (*onWrite)(TStream *, int, size_t);
  pd_write_t op;
  v8::Persistent<v8::Value> value;

  Writer(TStream *stream, v8::Local<v8::Uint8Array> data,
         void (*onWrite)(TStream *, int, size_t)) {
    // Create a persistent reference to prevent garbage collection
    value.Reset(data->GetIsolate(), data);
    // Extract buffer data and size from Uint8Array
    char *buf = Buffer::getBytes(data);
    size_t len = Buffer::getSize(data);
    pd_write_init(&op, buf, len, Writer::afterWrite); // init write in pandio library

    // Store the stream and callback function for later use
    this->stream = stream;
    this->onWrite = onWrite;
    op.udata = this;
  }

  // Reset persistent handle, allowing the GC to reclaim the value
  ~Writer() { value.Reset(); }

  static void afterWrite(pd_write_t *op, int status) {
    Writer *writer = static_cast<Writer *>(op->udata);
    if (writer->onWrite) {
      // pandio notifies only when full buffer is written (or when we get error)
      writer->onWrite(writer->stream, status, op->data.len);
    }

    delete writer;
  }
};

Sandboxed environment

Typical JS runtime runs inside sandbox, and this have some implications, because for example, you cannot simply pass buffer allocated by our pandio library to ArrayBuffer object. Any buffers must be allocated inside v8 engine memory space. For this reason, pandio avoids own allocations (user must allocate and manage objects) and if it has no choice, I have custom callback which acts as allocator.

v8::ArrayBuffer::NewBackingStore allocates read buffer inside v8 memory space:

void *TcpStream::readAllocator(pd_tcp_t *handle, size_t size) {
  Pand *pand = Pand::get();
  auto bs = v8::ArrayBuffer::NewBackingStore(
      pand->isolate, size, v8::BackingStoreInitializationMode::kUninitialized);
  TcpStream *stream = static_cast<TcpStream *>(handle->data);
  stream->read_bs = std::move(bs);

  return stream->read_bs->Data();
}

Unhandled async exceptions

Dealing with unhandled async exceptions is tricky.

v8 engine has callback SetPromiseRejectCallback. This callback reports events like v8::kPromiseRejectWithNoHandler and I initially thought I will use it for cool central error handling (logging and eventually aborting program).

But this code causes - v8::kPromiseRejectWithNoHandler to be reported first, but later v8::kPromiseHandlerAddedAfterReject will be reported:

async function throwErr() {
  throw new Error("some exception");
}

const result = throwErr();

result.catch((err) => {
  console.log('catch:', err.message);
})

So yeah, promise handler can be added after reject.

Typical way of handling this scenario is saving exception inside hash map. We give time to add handler until the end of current loop cycle.

At the end of event loop cycle, we check if hash map of our unhandled exceptions is not empty. If it is not empty, we will abort our program.

static std::unordered_map<int, v8::Global<v8::Value>> rejected_promises;

// runs at the end of each event loop cycle as 'after_tick' pandio hook
void Errors::checkPendingErrors(pd_io_t *ctx) {
  if (rejected_promises.empty()) {
    return;
  }

  Pand *pand = Pand::get();
  v8::Isolate *isolate = pand->isolate;
  v8::HandleScope handle_scope(isolate);
  v8::Local<v8::Context> context = isolate->GetCurrentContext();

  v8::Global<v8::Value> &result = rejected_promises.begin()->second;
  v8::Local<v8::Value> value = result.Get(isolate);
  // logs and abort program
  Errors::reportUncaught(value, true);
}

void Errors::promiseRejectedCallback(v8::PromiseRejectMessage message) {
  v8::Isolate *isolate = Pand::get()->isolate;
  v8::HandleScope handle_scope(isolate);

  v8::PromiseRejectEvent event = message.GetEvent();
  v8::Local<v8::Promise> promise = message.GetPromise();
  v8::Local<v8::Value> error = message.GetValue();

  int promiseId = promise->GetIdentityHash();

  switch (event) {
  case v8::kPromiseRejectWithNoHandler:
    rejected_promises[promiseId].Reset(isolate, error);
    break;
  case v8::kPromiseHandlerAddedAfterReject:
    if (rejected_promises.find(promiseId) != rejected_promises.end()) {
      rejected_promises[promiseId].Reset();
      rejected_promises.erase(promiseId);
    }
    break;
  default:
    return;
  }
}

Summary

This is my first blog post about PandJS development.

Currently we have:

  • TCP streams
  • Timers (setTimeout, setInterval)
  • ES6 modules support
  • Buffer data type

I slowly work on adding file system module, some experimental functions are already implemented in my pandio library.

I plan to start working on Streams API from web standard as well.
